Indiana Form M-233ST is a “Special Weight Single Trip Application” issued by the Indiana Department of Revenue. This permit is required for transport companies moving extra-heavy loads across specific state routes. It authorizes a single trip for vehicles that exceed standard weight limits but fall within the defined “special weight” maximums—specifically up to 134,000 pounds gross weight for most routes, or 90,000 pounds for others. The form legally validates the transport of commodities over a strictly defined network of highways, primarily in the industrial corridors of Northwest Indiana (such as Hammond, East Chicago, and Gary). It acts as a binding agreement where the driver and company attest that the vehicle’s dimensions and weights are accurate and that they will strictly adhere to the designated routes without unauthorized detours. The permit fee is listed as $42.50.
How to File Indiana Form M-233ST
Submission Instructions
While the form does not explicitly list a mailing address like tax forms, it is an application that must be authorized. Typically, these are processed through the Indiana Department of Revenue’s motor carrier services or permit office. The form states it is valid only if signed by both an authorized company officer and the driver.
Fee: $42.50
How to Complete Indiana Form M-233ST
Company and Contact Information
- Name of Transporting Company: Enter the legal name of the trucking or transport company.
- FEIN/SSN#: Provide the company’s Federal Employer Identification Number or the owner’s Social Security Number.
- Telephone Number: Enter a contact phone number for the company.
- Address Fields: Fill in the complete Street Address, City, State, and ZIP code of the company.
Trip and Vehicle Details
- Start Date: Enter the date the trip will begin.
- Start Time: Enter the specific time the trip will start.
- Fax Number: Provide a fax number for communication (if applicable).
- State Plated: Enter the state where the vehicle is registered.
- Make of Tractor: Specify the manufacturer of the truck tractor (e.g., Mack, Peterbilt).
- Model Year: Enter the year the tractor was manufactured.
- Full Vehicle Identification Number: Write the complete VIN of the tractor.
- License Plate Number: Enter the license plate number of the vehicle.
- Vehicle Type: Check the appropriate box to describe the configuration:
- Truck-Trailer
- Tractor-Trailer
- Other Towed
Dimensions
Verify the vehicle meets the legal limits by checking the status for:
- Overall Length: Must be “Legal”.
- Overall Width: Must be “Legal”.
- Overall Height: Must be “Legal”.
Allowable Weights and Specifications
Review the pre-printed weight limits to ensure compliance:
- Single Axle: Max 18,000 lbs.
- Axle Combination: Max 13,000 lbs per axle (exception: one tandem group up to 16,000 lbs per axle or 32,000 lbs total).
- Gross Weight: Max 134,000 lbs for Routes 1-21; Max 90,000 lbs for Route 22.
- Axle Spacing: Not less than 3’6″ between axles in a combination; not less than 8 feet between axle groups.
- Tire Weight: Max 800 lbs per inch of tire width.
Authorized Routes
The permit is only valid on the specific State Roads listed (1 through 22). These include segments of US 41, Highway 312, Highway 912, Highway 20, Highway 12, Highway 249, Highway 149, Highway 39, Highway 2, Highway 23, Highway 35, US 6, US 30, and State Road 9.
- Note: No other routes or detours are authorized unless directed by proper authorities.
Signatures
- Driver’s Signature / Date: The driver must sign and date to certify the vehicle description is accurate and they understand the rules.
- Company Owner or Responsible Officer: An authorized company representative must sign here.
- Driver’s Signature / Date (Second Line): There is a second line for the driver’s signature and date, often used to re-confirm or countersign the specific transport agreement.
